{{0}}.4mm Txiv neej Board To Board Plug BB0.4M-1.0

Product AttributesSupply Ability Cov Ntaub Ntawv Ntxiv Ntim Kev Xa Khoom<>

Txheej txheem cej luam

Yam khoom

Qauv No.: BB{{0}}.4M-1.0XXX02Brand: ANTENKInterface Hom: Ac/DcHousing: PlasticPin: BrassPoles: Lwm yam Daim ntawv thov: Lwm yamGender: Txiv neej Khoom siv: BrassSupport Card Number: OtherOperating Frequency: High FrequencyClass Keeb kwm: China

Muaj peev xwm muab cov ntaub ntawv ntxiv

Ntim: hnab packing, Tube packing, reel packingProductivity: 2000K / hli Kev thauj mus los: Dej hiav txwv, Cua, ExpressPlace ntawm lub hauv paus chiv keeb: Tuam TshojSupply muaj peev xwm: 2000K / hliCertificate: ISO9001HS Code: 8536909000Type: FCI, UnionPayment: TSO , FCA

Ntim Kev xa khoom

Kev Muag Khoom:

Daim / Daim

Hom pob:

hnab packing, Tube packing, reel packing

0.4mm Board rau Board txiv neej connector mating Qhov siab =1.00mm

Specifications:

1.Materlal:

1-1.Moulded feem: LCP resin (ul94-0).

1-2.Kev sib cuag thiab ncej: tooj liab alloy.

2. Kev kho deg:

2-1.Terminal feem; puag; Ni plating nto;

Au plating (tshwj tsis yog cov lus qhia davhlau ya nyob twg); nthuav tawm cov nickel feem.

2-2.Metal Clips: puag; Ni plating nto; Au flash plating

(tshwj tsis yog cov lus qhia davhlau ya nyob twg) lossis lub hauv paus; Ni plating nto;

Sn flash plating (tshwj tsis yog cov lus qhia davhlau ya nyob twg)

3. Yam ntxwv:

3-1.Rated voltage: 60V AC / DC

3-2.Rated curren:0.3A/contact(Max.5A ntawm tag nrho kev sib cuag)

3.3.Insulation resistance:Min.1000MΩ(initial)

3.4.Breakdown voltage: 150V AC fou 1 min.

3-5.Saltwater spray kuj (header thiab socket mated: 24 teev,

insulact resistance max.90mΩ.

3-6Contact resistance:Max.90mΩ.

3-7.Ambient kub: -55 degree ntxiv rau 85 degree.

3-8.Storage kub: -55 degree ntxiv rau 88 degree (khoom xwb);

-40 degree ntxiv rau 50 degree (emboss ntim).

3-9.Composite insertion force:Max.0.918N/contacts X contacts(initial).

3-10.Composite tshem tawm quab yuam:Min.0.165N/hu rau X hu.

3-11.Post tuav quab yuam:Min.0.49N/contacts.

3-12.Insertion thiab tshem tawm lub neej: 50 zaug.

FAQ

1, Can we get some samples? Any charges?

Yes, free existing labels, you need to pay shipping cost.

 2. How can we get a quote?

Contact us with specification: such as material, design, size, shape, color, quantity,  surface finishing, etc.

 3. Can you help with the design?Yes, Simply design free, special design need to pay.                                                                             4. What's the trade term and payment term?Amount less than 1000, 100 percent  paid before production, more than 1000 can be negotiated!

T/T, Western Union, PAYPAL etc.

5.  May I have new sample made with my design for confirmation?

Yes. Sample charge means set up charge for production line, little quantity  we suggest that straight for production. Large quantity we suggest that sample   first, and sample fee can be refund.

QUALITY CONTROL

Peb muajQC person stay on the production lines do to the inspection.All khooms yuav tsum tau kuaj xyuas ua ntej xa khoom.we ua inline soj ntsuam thiab zaum kawg tshuaj xyuas.

1.Txhua cov khoom siv raw tau kuaj xyuas thaum nws tuaj txog peb lub Hoobkas.

2.Txhua daim thiab lub logo thiab tag nrho cov ntsiab lus tshawb xyuas thaum lub sijhawm tsim khoom.

3.Txhua cov ntaub ntawv ntim tau kuaj xyuas thaum tsim khoom.

4.Txhua qhov kev tsim khoom zoo thiab ntim khoom tau kuaj xyuas zaum kawg tom qab ua tiav.

Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?A: Peb yog cov chaw tsim khoom tshwj xeeb hauv orthopedic thiab cov khoom ua si. Thiab peb pauv peb cov khoom nrog peb cov neeg siv khoom ncaj qha.

Q: Koj puas tuaj yeem ua OEM thiab ODM?

A: Yog, OEM thiab ODM yog ob qho tib si txais. Cov khoom siv, xim, style tuaj yeem hloov kho, qhov pib kom muaj nuj nqis peb yuav qhia tom qab peb tham.

Q: Peb puas tuaj yeem siv peb lub logo?

A: Yog lawm, peb tuaj yeem luam koj tus kheej lub logo raws li koj qhov kev thov.

Q: Koj muaj pes tsawg lub ntim?

A: We have five packages including PE bag, hand bag, zip lock bag, colorful box and
