Txheeb xyuas qhov sib txawv thiab ntau hom FFC Connectors thiab FPC Connectors

Niaj hnub no' cov ntaub ntawv txuas thiab cov qauv hloov pauv tas li. Nrog rau daim ntawv thov khoom, zaus, lub zog, daim ntawv thov ib puag ncig, thiab lwm yam, muaj ntau hom kev sib txuas. FFC connector yog hloov tau yooj yim ca cable connector. Nws yog ib yam tshiab ntawm cov ntaub ntawv cable ua los ntawm PET insulating cov ntaub ntawv thiab tsis tshua muaj nyias tinned ca tooj liab hlau, uas yog laminated los ntawm cov kab ntau lawm ntawm high-tech automation khoom. Nws yog hloov tau, hloov tau thiab foldable. , Nyias thickness, me me, kev sib txuas yooj yim, yooj yim disassembly, yooj yim los daws electromagnetic shielding (EMI). Cov hauv qab no feem ntau tham txog qhov sib txawv ntawm FFC connector thiab FPC connector, thiab feem ntau siv hom FFC connector.

Qhov sib txawv ntawm FFC connector thiab FPC connector

FFC connector yog ib tug saj zawg zog ca cable connector, thiab FPC connector yog ib tug saj zawg zog luam Circuit Court. Los ntawm kev tsim khoom ntawm ob lub connectors, txoj kev lawv tsim yog txawv:

1. FFC yog ib tug ca tooj liab ntawv ci sandwiched ntawm sab sauv thiab qis insulating ntawv ci zaj duab xis. Cov khoom tiav yog yooj yim dua thiab thicker.

2. FPC yog ua cov txheej txheem FCCL (hloov tooj liab clad ntawv ci) los ntawm cov tshuaj etching kom tau txais cov kab hluav taws xob hloov tau yooj yim nrog cov qauv sib txawv ntawm ib sab thiab ob sab thiab ntau txheej txheej.

Hais txog tus nqi, ib txwm FFC connectors yog pheej yig dua. Yog tias tus nqi tsim khoom raug coj mus rau hauv tus account, ntau lub tuam txhab yuav nyiam siv FFC txuas nrog cov qauv tsim.

7 hom ntawm FFC connectors

Hom A: Ob qhov kawg txuas nrog thiab cov phaj txhawb nqa tau muab tso rau ntawm daim kab xev insulating;

Hom B: Hla lub phaj reinforcing thiab muab tshuaj txhuam ncaj qha rau ntawm daim kab xev insulating;

Hom C: Cov hlau nplaum ntawm ob qhov kawg yog ncaj qha pasted rau ntawm tus neeg xyuas pib;

Hom D: Hla cov hlau nplaum ntawm ob qho kawg thiab muab tshuaj txhuam ncaj qha rau ntawm tus neeg xyuas pib;

Hom E: Ib kawg ntawm lub phaj reinforcing yog txuas nrog cov ntaub nplaum insulating, thiab lwm qhov kawg yog ncaj qha soldered;

Hom F: Cov phaj txhawb nqa ntawm ob qho kawg yog txuas ncaj qha mus rau daim kab xev insulating, thiab sab hauv ib nrab yog tev tawm;

Hom G: ncaj qha soldering ntawm ob qho kawg.

Feem ntau hais lus, txoj kev loj hlob ntawm niaj hnub no' s FFC connector technology nthuav tawm cov yam ntxwv hauv qab no: kev kub ceev thiab cov teeb liab kis tau tus mob, kev koom ua ke ntawm ntau yam teeb liab kis, miniaturization thiab miniaturization ntawm cov khoom ntim, cov khoom siv qis, thiab kev sib cuag. termination Txoj kev yog nto-mounted, modular ua ke, yooj yim plug-in thiab hais txog.
